1.27mm Pitch Pin Header 50 pin Double Rows Straight Dip Type equivalent to FTS Series
1.27mm Pitch Pin Header 50 pin Double Rows Straight Dip Type equivalent to FTS Series
  • 1.27mm Pitch Pin Header 50 pin Double Rows Straight Dip Type equivalent to FTS Series

  • Part No : PHVD127-50G-1680
  • Specifications:.

    Current rating:1.0 Amps

    Voltage rating:50V AC/DC

    Contact resistance:20mohm max.

    Insulation resistance:1,000Mohm min.

    Withstanding Voltage:500v For One Minute

    Operating Temperature:-25’C ~ +105’C

    Material
    Insulator:High Temp.Plastic(Nylon 6T UL94V-0 )

    Standard Color:Black

    Contact:Copper Alloy

    Plated:Tin Plated


  • Inquiry now
  • Products Drawing

Detailed description


Understanding the 1.27mm Pitch Pin Header Double Rows Straight DIP Type: Equivalent to FTS Series

Introduction to Pin Headers

Pin headers are essential components in the world of electronics, serving as connectors that allow various electronic devices and components to interface with one another. They are ubiquitous in printed circuit boards (PCBs), connecting different parts of an electronic system. These connectors are vital for facilitating data transmission, power supply, and signal processing in a wide range of applications, from consumer electronics to industrial automation.

One specific type of pin header that has garnered attention in various applications is the 1.27mm Pitch Pin Header Double Rows Straight DIP Type, which is often compared to the FTS Series. This type of pin header is known for its compact design, reliability, and versatility, making it an ideal choice for applications where space is limited but performance cannot be compromised.

What is a 1.27mm Pitch Pin Header?

The term “1.27mm pitch” refers to the spacing between the center points of two adjacent pins on the header. A 1.27mm pitch pin header, therefore, has a relatively small spacing, making it suitable for high-density applications where space on the PCB is at a premium. The smaller pitch allows for more connections in a given area, which is particularly important in modern electronics, where devices are becoming increasingly compact.

Pin headers come in various configurations, with the double rows straight DIP (Dual In-line Package) type being one of the most common. The double-row configuration allows for more pins to be placed in a smaller area, which is beneficial for applications that require multiple connections. The straight DIP type refers to the orientation of the pins, which are designed to be inserted directly into the PCB and soldered in place, providing a secure and reliable connection.

The FTS Series: A Benchmark in Quality and Performance

The FTS Series is a well-known line of connectors in the electronics industry, recognized for its high quality and reliability. These connectors are designed to meet the demanding requirements of modern electronics, providing a dependable interface for a variety of applications. The FTS Series is often used as a benchmark for comparing other pin headers, particularly those with similar specifications, such as the 1.27mm pitch pin header double rows straight DIP type.

FTS Series connectors are known for their durability, with gold-plated contacts that provide excellent conductivity and corrosion resistance. They are also designed to withstand the rigors of repeated mating and unmating cycles, ensuring long-term reliability in even the most demanding environments. The compact design of the FTS Series makes it ideal for applications where space is limited, while the robust construction ensures that these connectors can handle the electrical and mechanical stresses they are subjected to in various applications.

Equivalent Pin Headers: The 1.27mm Pitch Double Rows Straight DIP Type

The 1.27mm pitch pin header double rows straight DIP type is often considered an equivalent to the FTS Series, offering similar performance characteristics in a compact and reliable package. These pin headers are designed to provide a high-density connection solution, making them suitable for a wide range of applications, including telecommunications, consumer electronics, automotive systems, and industrial automation.

Key Features of the 1.27mm Pitch Pin Header Double Rows Straight DIP Type:
  1. Compact Design: The 1.27mm pitch allows for a high-density connection solution, making these pin headers ideal for applications where space is limited.

  2. Double Rows Configuration: The double rows configuration provides more connection points in a smaller area, increasing the number of possible connections on the PCB.

  3. Straight DIP Type: The straight DIP design allows the pins to be inserted directly into the PCB and soldered in place, providing a secure and reliable connection.

  4. Durability: These pin headers are designed to withstand the rigors of repeated use, with gold-plated contacts that ensure excellent conductivity and corrosion resistance.

  5. Versatility: The 1.27mm pitch pin header double rows straight DIP type is suitable for a wide range of applications, from high-performance computing to consumer electronics.

  6. Cost-Effective: While offering similar performance characteristics to the FTS Series, these pin headers are often available at a more competitive price point, making them an attractive option for cost-sensitive applications.

Applications of the 1.27mm Pitch Pin Header Double Rows Straight DIP Type

The versatility and compact design of the 1.27mm pitch pin header double rows straight DIP type make it suitable for a wide range of applications. Some of the key areas where these pin headers are commonly used include:

  1. Telecommunications: In telecommunications equipment, where space is limited and reliability is crucial, the 1.27mm pitch pin header double rows straight DIP type provides a compact and reliable connection solution for various components.

  2. Consumer Electronics: From smartphones to gaming consoles, the demand for smaller, more powerful devices has driven the need for compact, high-density connectors. The 1.27mm pitch pin header double rows straight DIP type is ideal for these applications, offering a space-saving solution without compromising on performance.

  3. Automotive Systems: In modern vehicles, electronic systems play a critical role in everything from engine management to infotainment. The 1.27mm pitch pin header double rows straight DIP type provides a reliable connection solution for these systems, ensuring that they function correctly even in harsh automotive environments.

  4. Industrial Automation: In industrial automation, where reliability and durability are paramount, the 1.27mm pitch pin header double rows straight DIP type offers a robust connection solution for various control and monitoring systems.

  5. Medical Devices: In the medical field, where precision and reliability are crucial, the 1.27mm pitch pin header double rows straight DIP type provides a dependable connection solution for a wide range of devices, from diagnostic equipment to patient monitoring systems.

The Importance of Quality in Pin Headers

When it comes to electronic connectors, quality is of utmost importance. A poor-quality connector can lead to unreliable connections, signal loss, and even system failures, which can have serious consequences, especially in critical applications such as medical devices or automotive systems. This is why it is essential to choose pin headers that meet stringent quality standards, such as those found in the FTS Series or equivalent products like the 1.27mm pitch pin header double rows straight DIP type.

Quality pin headers are designed to provide a reliable connection over the long term, with features such as gold-plated contacts for excellent conductivity and corrosion resistance. They are also built to withstand the mechanical stresses of repeated mating and unmating cycles, ensuring that they can be used in demanding environments without compromising performance.

Selecting the Right Pin Header for Your Application

When selecting a pin header for your application, there are several factors to consider, including:

  1. Pitch: The pitch of the pin header should be chosen based on the space available on the PCB and the number of connections required. The 1.27mm pitch is ideal for high-density applications where space is limited.

  2. Configuration: The number of rows and the orientation of the pins (e.g., straight DIP) should be selected based on the specific requirements of your application.

  3. Material and Plating: The material of the contacts and the type of plating used can affect the performance and durability of the pin header. Gold-plated contacts, for example, offer excellent conductivity and corrosion resistance.

  4. Mechanical Strength: The pin header should be able to withstand the mechanical stresses of your application, including repeated mating and unmating cycles.

  5. Environmental Conditions: Consider the environmental conditions in which the pin header will be used, including temperature, humidity, and exposure to chemicals or other harsh conditions.

  6. Cost: While quality should always be a priority, it is also important to consider the cost of the pin header, especially in cost-sensitive applications.

By carefully considering these factors, you can select a pin header that meets the specific needs of your application, ensuring reliable performance and long-term durability.

Conclusion

The 1.27mm Pitch Pin Header Double Rows Straight DIP Type, equivalent to the FTS Series, offers a high-quality, reliable connection solution for a wide range of applications. With its compact design, robust construction, and excellent performance characteristics, this type of pin header is ideal for use in telecommunications, consumer electronics, automotive systems, industrial automation, and medical devices.

When selecting a pin header for your application, it is important to consider factors such as pitch, configuration, material, mechanical strength, and environmental conditions to ensure that you choose a connector that meets your needs. By prioritizing quality and reliability, you can ensure that your electronic systems perform optimally and maintain their functionality over the long term.
