AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P
- Part No : HS635-06
-
Current Rating: 13.0 Amps
Voltage Rating: 600V AC/DC
Contact Resistance: 20m Ohm Max
Insulator Resistance: 1000M Ohm Min
Withstanding Voltage: 5000V AC/minute
Operating Temperature Range: -55℃~+105℃
Material:
Plastic: Nylon 66 (UL94V-2)
Contacts: Brass
Plating: TIN Plated
Wire range: #16~#22
- Inquiry now
- Products Drawing
Detailed description
AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P
1.What is AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P？
AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P Composed of a male (Pin) and female (Socket) insulated housing with a spacing of AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P , the connector is internally crimped with metal terminals and has a hook locking mechanism. It produces a locking sound when inserted and is widely used in various electrical and electronic devices that require safe power
connections
2.Which industries apply AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P？
a.AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P House hold appliances: refrigerators, freezers, washing machines, dryers, heat pumps, etc
b.AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P Industrial equipment: industrial control systems, automation equipment, generator systems, industrial machinery and construction equipment
c.AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P Medical and Business: Medical equipment, hospital beds, photocopiers, printers, vending machines, and gas dispensers
d.AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P Transportation and Lighting: Commercial Vehicles, RVs, Lighting Systems, Security Systems
3.Hoyato AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P can povide a pefect ompatibility solution and compare it with AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P Pin to Pin part numbers in the table
| Product Description | TE (AMP) part.no | Hoyato part No. |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P 2P |
1-480698-0/794814-13/350777-1 |
HS635-02/HS635-02-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P 3P |
1-480700-0/794901-13/350766-1 |
HS635-03/HS635-03-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P 4P |
1-480702-1/794799-13/350779-1 |
HS635-04/HS635-04-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P 5P |
1-480763-0/350809-1 |
HS635-05/HS635-05-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P 6P |
640585-1/1-480704-0/794535-13/794096-15/640581-1/350715-1 |
HS635-06/HS635-06-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P 8P |
640586-1/640582-1 |
HS635-08/HS635-08-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P 9P |
1-480706-0/794537-13/350720-1 |
HS635-09/HS635-09-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P 10P |
926302-1/926-302-3 |
HS635-10/HS635-10-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P 12P |
1-480708-0/794853-13/350735-1 |
HS635-12/HS635-12-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P 15P |
1-480710-0/794546-13/350736-1 |
HS635-15/HS635-15-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P Cirm socket Terminal |
350570-31 |
HS635T-1822 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P Cirm socket Terminal | 350874-3 | HS635T-1620 |
Matching connector：
| Product Description | TE (AMP) part.no | Hoyato part No. |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P 2P | 641963-1/350428-1/350428-4/641963-3/350786-1/350786-3/641964-3/1-641964-15 | WFPV635-02/WFPV635-02-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P 3P | 641965-1/350429-1/350429-4/350789-1/350789-3/641966-3/1-641966-14 | WFPV635-03/WFPV635-03-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P 4P | 641967-1/350430-1/350430-4/350792-1/350792-3/641968-1 | WFPV635-04/WFPV635-04-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P 5P | 640466-1/640466-3/643405-1/640900-1/
640900-3/643406-1 |
WFPV635-05/WFPV635-05-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P 6P | 641832-1/641832-3/643407-1/641831-1/
641831-3/643408-1 |
WFPV635-06/WFPV635-06-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P 8P | 641825-1/641828-1/643410-1/643410-3 | WFPV635-08/WFPV635-08-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P 9P | 350432-1/350432-4/350712-1/350712-4/641971-1/641971-4/641972-1/1-641972-14
/641972-3 |
WFPV635-09/WFPV635-09-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P 12P | 350433-1/350433-4/350713-1/350713-4/641973-1/641974-1/1-641974-14/641974-3 | WFPV635-12/WFPV635-12-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P 15P | 350434-1/350434-4/350714-1/350714-4/641975-1/641974-1/641976-1
/641976-3 |
WFPV635-15/WFPV635-15-V0 |
Matching CAP Housing：
| Product Description | TE/AMP part.no | Hoyato part No. |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P Pin Housing 2P | 1-480699-0/794815-13/350788-1 | HP635-02/HP635-02-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P Pin Housing 3P | 1-480701-0/794900-13/350767-1 | HP635-03/HP635-03-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P Pin Housing 4P | 1-480703-0/794707-3/350780-1 | HP635-04/HP635-04-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P Pin Housing 5P | 1-480764-03/794863-13/350810-1 | HP635-05/HP635-05-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P Pin Housing 6P | 926307-1/926307-3/1-480705-0/794536-13/350781-1 | HP635-06A/HP635-06A-V0/HP635-06/HP635-06-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P Pin Housing 8P | 926308-1/926308-3 | HP635-08/HP635-08-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P Pin Housing 9P | 1-480707-0/794538-13/350782-1 | HP635-09/HP635-09-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P Pin Housing 12P | 1-480709-0/794727-13/350783-1 | HP635-15/HP635-15-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P Pin Housing 15P | 1-480711-0 /794545-13/350784-1 | HP635-12/HP635-12-V0 |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P pin Terminal awg 18~awg22 | 350538-3/350538-6 | HP635T-1822-A/HP635SG-1822-A |
| AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P pin Terminal awg 16~awg 20 | 350873-3/350922-6 | HP635T-1620-A/HP635SG-1620-A |
Optimize performance with 1-480704-0, a solution tailored for excellence. Elevate your projects with precision and reliability in every connection, setting new standards in electrical engineering.
Melissa Lee
Email:sales05@dghoyato.com
Skype:limiao425
Phone/Whatsapp:86-13337908889
AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P
|
Connector Type
|
Crimp Housings
|
|||
|
Orginal P/N
|
AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P | |||
|
Pitch – Mating
|
6.35mm
|
|||
|
Number of Positions
|
02-15
|
|||
|
Number of rows
|
2
|
|||
|
Flammability
|
94V-2
|
|||
|
Contact Termination
|
Crimp
|
|||
|
Packaging Type
|
Bag
|
|||
Hoyato AMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P consist of a receptacle and plug set in a variety of single and multiple row configurations withAMP 1-480704-0 MATE-N-LOK Plug Housing connector 6P centerlines. They are manufactured of Nylon 6/6 with a flammability rating of UL94V-2 or UL94V-0.
