6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow
- Part No : WFPV635-03-YL-V0
-
Current Rating: 13.0 AC/DC
Voltage Rating: 600V AC/DC
Contact Resistance: 20m ohm. max.
Insulation Resistance: 1,000M ohm.min.
Withstanding Voltage: 5,000V AC/minute
Operating Temperature Range: -55°C to +105°C
Material and Finish
Insulator: Nylon 66 (UL94V-2)
Insulator Color: Yellow
Contact: Tin Plated
Finish: Tin Plated - Inquiry now
- Products Drawing
Detailed description
6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow
1.What is 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow？
6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow Composed of a male (Pin) and female (Socket) insulated housing with a spacing of 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow, the connector is internally crimped with metal terminals and has a hook locking mechanism. It produces a locking sound when inserted and is widely used in various electrical and electronic devices that require safe power
connections
2.Which industries apply 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow？
a.6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow House hold appliances: refrigerators, freezers, washing machines, dryers, heat pumps, etc
b.6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow Industrial equipment: industrial control systems, automation equipment, generator systems, industrial machinery and construction equipment
c.6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow Medical and Business: Medical equipment, hospital beds, photocopiers, printers, vending machines, and gas dispensers
d.6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow Transportation and Lighting: Commercial Vehicles, RVs, Lighting Systems, Security Systems
3.Hoyato 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow can povide a pefect ompatibility solution and compare it with 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow Pin to Pin part numbers in the table
| Product Description | TE (AMP) part.no | Hoyato part No. |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow 2P | 641963-1/350428-1/350428-4/641963-3/350786-1/350786-3/641964-3/1-641964-15 | WFPV635-02/WFPV635-02-V0 |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow 3P | 641965-1/350429-1/350429-4/350789-1/350789-3/641966-3/1-641966-14 | WFPV635-03/WFPV635-03-V0 |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow 4P | 641967-1/350430-1/350430-4/350792-1/350792-3/641968-1 | WFPV635-04/WFPV635-04-V0 |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow 5P | 640466-1/640466-3/643405-1/640900-1/
640900-3/643406-1 |
WFPV635-05/WFPV635-05-V0 |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow 6P | 641832-1/641832-3/643407-1/641831-1/
641831-3/643408-1 |
WFPV635-06/WFPV635-06-V0 |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow 8P | 641825-1/641828-1/643410-1/643410-3 | WFPV635-08/WFPV635-08-V0 |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow 9P | 350432-1/350432-4/350712-1/350712-4/641971-1/641971-4/
641972-1/1-641972-14 /641972-3 |
WFPV635-09/WFPV635-09-V0 |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow 12P | 350433-1/350433-4/350713-1/350713-4/641973-1/641974-1/1-641974-14
/641974-3 |
WFPV635-12/WFPV635-12-V0 |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow 15P | 350434-1/350434-4/350714-1/350714-4/641975-1/641974-1/641976-1
/641976-3 |
WFPV635-15/WFPV635-15-V0 |
Matching connector：
| Product Description | TE (AMP) part.no | Hoyato part No. |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow Housing 2P |
1-480698-0/794814-13/350777-1 |
HS635-02/HS635-02-V0 |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow Plug Housing 3P |
1-480700-0/794901-13/350766-1 |
HS635-03/HS635-03-V0 |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow Plug Housing 4P |
1-480702-1/794799-13/350779-1 |
HS635-04/HS635-04-V0 |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow Plug Housing 5P |
1-480763-0/350809-1 |
HS635-05/HS635-05-V0 |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow Plug Housing 6P |
640585-1/1-480704-0/794535-13/794096-15/640581-1/350715-1 |
HS635-06/HS635-06-V0 |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow Plug Housing 8P |
640586-1/640582-1 |
HS635-08/HS635-08-V0 |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow Plug Housing 9P |
1-480706-0/794537-13/350720-1 |
HS635-09/HS635-09-V0 |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow Plug Housing 10P |
926302-1/926-302-3 |
HS635-10/HS635-10-V0 |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow Plug Housing 12P |
1-480708-0/794853-13/350735-1 |
HS635-12/HS635-12-V0 |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow Plug Housing 15P |
1-480710-0/794546-13/350736-1 |
HS635-15/HS635-15-V0 |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow Cirm socket Terminal |
350570-31 |
HS635T-1822 |
| 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow Cirm socket Terminal | 350874-3 | HS635T-1620 |
Dongguan Lanbo is a professional 6.35mm 350789-1 PCB Header Mata N Lok Connector 3p yellow manufacturer with robust R&D capability.1.0/1.25/1.5/2.0/2.5/3.0/3.5/4.0/5.08/5.7/6.2/6.35mm pitch male female mating connector can be providedpins.www.dghoyato.com
With professional technical and management team, we offer the best service and products. We have followed the operation principle of quality gain survival/technique gain development and market-oriented/service-oriented that we hope to cooperate with all walks of life and create the brilliancy together.
20 years experience,Specialize in FPC, Pin header, USB, Board to board, Wire to board, PCB socket, etc
